| Strap material |
Suitable for polyester (PET) or Polypropylene ( PP) |
| Max. Strap width |
16mm (5/8” ), 19mm ( 3/4” ) |
| Strap thickness |
PET: 0.55-1.05mm ( .022 - .04 inches )
PP: 0.75mm- 1.05mm ( .029- .04 inches )
|
| Max. tension Kgs/ N |
350 KGS ( 3500 N ) for PET, 180 KGS for PP
|
| Air hose requirement |
minimum 1/4”I.D.
(Coupling, mountings and fittings must not fall below this ) |
| Air pressure requirement |
minimum 6 bar (6Kg / / 87PSI)
up to 8 bar (8kg / / 116PSI)
|
| Sealing time adjustment |
1.0-8.0 seconds. |
| Sealing efficiency |
85+ - 5% of strap breaking strength (varies based on strap quality, strap specification, air pressure, set sealing time and operation habit.)
|
