TITAN VS31打包机机头




短号
长号
英文名
名称
2
120001-2
Cap screw
螺帽
3
120001-3
Spring washer
弹簧垫圈
4
120001-4
Heaf bar
夹板
5
120001-5
Cap screw
螺帽
6
120001-6
Federring
垫圈
8
120001-8
Cap screw
螺帽
9
120001-9
Spring washer
弹簧垫圈
10
120001-10
Cap screw
螺帽
11
120001-11
Plate
垫片
12
120001-12
Swivel joint
回转接头
13
120001-13
Pawl
棘爪
14
120001-14
Cylindrical pin
圆柱销
15
120001-15
Cylindrical pin
圆柱销
16
120001-16
Valve block
气阀塞子
17
120001-17
Cap screw
螺帽
18
120001-18
Ball
弹子
19
120001-19
Compression spring
弹簧
20
120001-20
round gasket
垫圈
21
120001-21
tappet
梃杆
22
120001-22
plug
插销
23
120001-23
hexagonal screw
螺丝
24
120001-24
Spring washer
弹簧垫圈
25
120001-25
initiator 20-250v
过顶板
26
120001-26
initiator 20-250v
过顶板
27
120001-27


28
120001-28
initiator 10-55v
过顶板
29
120001-29
initiator 10-55v
过顶板
30
120001-30
tube
气管
31
120001-31
initiator 10-55v
过顶板
32
120001-32
initiator 90-250v
过顶板
33
120001-33
Spring washer
弹簧垫圈
34
120001-34
hexagonal nut
六角螺帽
51
120001-51
Cylindrical pin
圆柱销
52
120001-52
round gasket
垫圈
53
120001-53
Swivel joint
回转接头
54
120001-54
cover plate
盖板
55
120001-55
Cap screw
螺帽
56
120001-56
Spring washer
弹簧垫圈
57
120001-57
cylinder
汽缸
58
120001-58
piston rod
定位杆
59
120001-59
Dowel pin
合缝销
60
120001-60
sheet metal
金属片
61
120001-61
Cap screw
螺帽
62
120001-62
Spring washer
弹簧垫圈
63
120001-63
washer
垫圈
64
120001-64
Cap screw
螺帽
65
120001-65
Spring washer
弹簧垫圈
66
120001-66
self-aligning ball bearing
自动对位轴承
67
120001-67
shim
薄垫片
68
120001-68
cylindercover
汽缸盖
69
120001-69
Cap screw
螺帽
70
120001-70
round gasket
垫圈
71
120001-71
Swivel joint
回转接头
72
120001-72
reducing nipple
变内径内螺纹接头
73
120001-73
piston
活塞
74
120001-74
piston packing
填密活塞
75
120001-75
piston guide ring
活塞环
76
120001-76
bushing
轴衬
77
120001-77
pistonrod packing
填密活塞
79
120001-79
Swivel joint
回转接头
80
120001-80
piston pin
活塞销
81
120001-81
piston
活塞
82
120001-82
washer
垫圈
83
120001-83
hexagonal nut
六角螺帽
84
120001-84
cylindercover
汽缸盖
85
120001-85
Cap screw
螺帽
86
120001-86
round gasket
垫圈
87
120001-87
Swivel joint
回转接头
88
120001-88
reducing nipple
变内径内螺纹接头
89
120001-89
receiving lug

91
120001-91
rod packing
O型圈
93
120001-93
spacer
垫片
94
120001-94
silver house
软管
95
120001-95
Swivel joint
回转接头
96
120001-96
piston pin
活塞销
97
120001-97
sleeve
轴子
100
120001-100
terminal box

101
120001-101
Cap screw
螺帽
102
120001-102
Spring washer
弹簧垫圈
103
120001-103
Valve block
气阀塞子
104
120001-104
Cap screw
螺帽
105
120001-105
Cap screw
螺帽
106
120001-106
Spring washer
弹簧垫圈
107
120001-107
round gasket
垫圈
108
120001-108
round gasket
垫圈
109
120001-109
straight pipe union
直活管节
110
120001-110
Swivel joint
回转接头
111
120001-111
battery plate
蓄电池极板
112
120001-112
6/2 way valve
6/2式阀
113
120001-113
Cap screw
螺帽
114
120001-114
Swivel joint
回转接头
116
120001-116
silver house
软管
117
120001-117
silver house
软管
118
120001-118
pipe
气管
119
120001-119
pipe
气管
120
120001-120
silver house
软管
121
120001-121
pipe
气管
124
120001-124
straight pipe union
直活管节
125
120001-125
Swivel joint
回转接头
126
120001-126
silver house
软管
127
120001-127
silver house
软管
129
120001-129
pipe
气管
130
120001-130
Cap screw
螺帽
131
120001-131
Spring washer
弹簧垫圈
134
120001-134
round gasket
垫圈
135
120001-135
round gasket
垫圈
136
120001-136
2/2 way valve without

139
120001-139
joint
接头
140
120001-140
Swivel joint
回转接头
141
120001-141
silver house
软管
142
120001-142
Swivel joint
回转接头
143
120001-143
non reduced swivel joint
回转接头
144
120001-144
silver house
软管
145
120001-145
cone reducing connection
锥形接头
146
120001-146
adjustable l-connection
可调节的接头
147
120001-147
silver house
软管
148
120001-148
Swivel joint
回转接头
149
120001-149
transducer
转换器
150
120001-150
Cap screw
螺帽
151
120001-151
Cap screw
螺帽
152
120001-152
straight pipe union
直活管节
154
120001-154
5/4 way valve without
阀主心
155
120001-155
Cap screw
螺帽
156
120001-156
Swivel joint
回转接头
157
120001-157
straight pipe union
直活管节
158
120001-158
pipe
气管
159
120001-159
splash lubricator
润滑器
160
120001-160
reducing nipple
变内径内螺纹接头
161
120001-161
plug nipple
变内径内螺纹接头
162
120001-162
coupling
接头
164
120001-164
distance collar
定距环
170
120001-170
silencer
消声器
171
120001-171
pressure gauge
压力计
172
120001-172
interrnediate sheet
夹板
173
120001-173
5/4 way valve without
阀主心
174
120001-174
Cap screw
螺帽
175
120001-175
distance collar
定距环
176
120001-176
double check valve
双单向阀
177
120001-177
double nipple
双向短接管
180
120001-180
round gasket
垫圈
181
120001-181
throttle(reducing)screw
变径螺丝
182
120001-182
hexagonal nut
六角螺帽
183
120001-183
L-pipe union
L型接头
184
120001-184
cover
盖子
185
120001-185
countersink sewrew
锥形螺丝
186
120001-186
filter
过滤器
187
120001-187
sound absorber inset
内置减振器
188
120001-188
quick vent valve
快速排气阀
189
120001-189
straight pipe union
直活管节
190
120001-190
straight screwed socket
螺口插座
191
120001-191
gasket
垫圈
192
120001-192
actuating magnet
193
120001-193
conducing box with luminate
194
120001-194
actuating magnet
195
120001-195
conducing box with luminate
196
120001-196
actuating magnet
197
120001-197
conducing box with luminate
198
120001-198
actuating magnet
199
120001-199
conducing box with luminate
200
120001-200
clarnp holder
支架
201
120001-201
Cylinder pin
圆柱销
202
120001-202
Cylinder pin
圆柱销
203
120001-203
cutting plate ,right
右剪切板
205
120001-205
Cap screw
螺帽
207
120001-207
Cap screw
螺帽
208
120001-208
counter blade
对刃
209
120001-209
cutting blade
切刀
211
120001-211
spacer
垫片
212
120001-212
Cap screw
螺帽
213
120001-213
Spring washer
弹簧垫圈
216
120001-216
lower blade pin
下切刀销子
217
120001-217
withdrawal pin
轴杆
218
120001-218
roller
滚轴
219
120001-219
roller pin
滚针
221
120001-221
clamping sleeve
压紧套筒
222
120001-222
clamping sleeve
压紧套筒
223
120001-223
distance collar
定距环
224
120001-224
distance collar
定距环
225
120001-225
clarnping leaver pin
杆销
250
120001-250
hexagonal nut
六角螺帽
251
120001-251
tension washer
拉紧垫圈
252
120001-252
junction box
接线盒
253
120001-253
mounted housing

254
120001-254
plug insert
插栓
255
120001-255
screw connection
连接螺丝
256
120001-256
dummy plug
插销
257
120001-257
line-up terminal
一字型接线端
258
120001-258
end plate
侧板
259
120001-259
carrier rail
横杆
260
120001-260
fixed bridge

265
120001-265
arrow
标杆
266
120001-266
Cap screw
螺帽
267
120001-267
separating disc
圆盘
268
120001-268
end clamp
夹钳
269
120001-269
clamp for neutral
夹钳
270
120001-270
wire sleeve
金属丝袖子
271
120001-271
simplex card

272
120001-272
simplex card
271
273
120001-273
simplex card
271
301
120001-301
Cylinder pin
圆柱销
302
120001-302
Cylinder pin
圆柱销
303
120001-303
Cap screw
螺帽
304
120001-304
locking washer
锁紧垫圈
305
120001-305
guide roller
导向辊
306
120001-306
guide roller
导向辊
307
120001-307
drive housing
传动箱
308
120001-308
Cap screw
螺帽
309
120001-309
threaded pin
销子
310
120001-310
needle (roller)bearing
滚针轴承
311
120001-311
DU bushing
轴衬
312
120001-312
Cap screw
螺帽
313
120001-313
hexagonal nut
六角螺帽
314
120001-314
short stroke cylinder
短冲程汽缸
315
120001-315
Cap screw
螺帽
316
120001-316
Swivel joint
回转接头
317
120001-317
reducing nipple
变内径内螺纹接头
318
120001-318
pneumatic cylinder
气压缸
319
120001-319
Cap screw
螺帽
320
120001-320
Spring washer
弹簧垫圈
321
120001-321
straight pipe union
直活管节
325
120001-325
pin
销子
326
120001-326
hexagonal nut
六角螺帽
327
120001-327
tension washer
拉紧垫圈
328
120001-328
locking washer
锁紧垫圈
329
120001-329


330
120001-330
rocker
摇杆
331
120001-331
taper ball bearing
滚球轴承
332
120001-332
gasket
垫圈
333
120001-333
DU bushing
轴衬
334
120001-334
cover
盖子
335
120001-335
gasket
垫圈
336
120001-336
needle case
轴承
337
120001-337
Cap screw
螺帽
338
120001-338
transport shaft
传输轴
339
120001-339
retaining ring
定位环
341
120001-341
flange
凸缘
342
120001-342
Cap screw
螺帽
343
120001-343
Cap screw
螺帽
344
120001-344
spring pin
弹簧销子
345
120001-345
tension spring
张力簧
347
120001-347


348
120001-348
needle bushing
轴衬
349
120001-349
gasket
垫圈
350
120001-350


351
120001-351
needle bushing
轴衬
352
120001-352
gasket
垫圈
353
120001-353
counter roller
滚筒
354
120001-354
shaft
轴衬
355
120001-355
washer
垫圈
356
120001-356
retaining ring
定位环
357
120001-357
torsion spring
转矩弹簧
358
120001-358
washer
垫圈
359
120001-359
Cap screw
螺帽
360
120001-360
locking washer
锁紧垫圈
361
120001-361
shaft
轴衬
362
120001-362
adjusting spring
调整弹簧
377
120001-377
tight-fit spring
紧密配合弹簧
378
120001-378
Spring washer
弹簧垫圈
379
120001-379
hexagonal nut
六角螺帽
380
120001-380
Cap screw
螺帽
382
120001-382
inner ring
内环
383
120001-383
conter roller
滚筒
384
120001-384
eccentric
档板
385
120001-385
needle bushing
轴衬
386
120001-386
gasket
垫圈
387
120001-387
needle taper ball bearing
滚针轴承
390
120001-390
shaft
391
120001-391
adjusting spring
调整弹簧
392
120001-392
locking washer
锁紧垫圈
393
120001-393
retaining ring
定位环
394
120001-394
hinged lever,right
右铰链控制杆
395
120001-395
clamping sleeve
压紧套筒
400
120001-400
Cap screw
螺帽
401
120001-401
Spring washer
弹簧垫圈
403
120001-403
reducing nipple
变内径内螺纹接头
404
120001-404
bracket
支架
405
&, amp;, lt;, /TD>
120001-405
Cap screw
螺帽
406
120001-406
locking washer
锁紧垫圈
407
120001-407
interrnadlate ring

408
120001-408
washer
垫圈
409
120001-409
contersunk screw
锥形螺丝
410
120001-410
slide rod
拉杆
411
120001-411
angle joint
角接头
412
120001-412
hexagonal nut
六角螺帽
413
120001-413
compressed air motor
气动马达
414
120001-414
straight pipe union
直活管节
416
120001-416
compressed air motor
气动马达
417
120001-417
spring pin
弹簧销子
418
120001-418
toothed wheel
齿轮
419
120001-419
dowel pin
开槽销
420
120001-420
rack
支架
421
120001-421
shaft
422
120001-422
flange
凸缘
423
120001-423
DU bushing
轴衬
424
120001-424
Cap screw
螺帽
425
120001-425
needle bushing
轴衬
426
120001-426
gasket
垫圈
427
120001-427
Cap screw
螺帽
428
120001-428
Spring washer
弹簧垫圈
429
120001-429
Cap screw
螺帽
430
120001-430
Cap screw
螺帽
431
120001-431
locking washer
锁紧垫圈
432
120001-432
Cap screw
螺帽
433
120001-433
Spring washer
弹簧垫圈
435
120001-435
E-angle screwing
螺纹角连接
438
120001-438
Cap screw
螺帽
440
120001-440
tightening disc
固定圆盘
441
120001-441
Cap screw
螺帽
444
120001-444
Cap screw
螺帽
446
120001-446
tightening disc
固定圆盘
447
120001-447
Cap screw
螺帽
450
120001-450
Cylindrical pin
圆柱销
451
120001-451
Cap screw
螺帽
452
120001-452
Spring washer
弹簧垫圈
453
120001-453
hexagonal nut
六角螺帽
455
120001-455
DU bushing
轴衬
460
120001-460
key
461
120001-461
Cap screw
螺帽
462
120001-462
locking washer
锁紧[止动, 防松]垫圈
465
120001-465
DU-washer
垫圈
468
120001-468
headless pin
无头销
469
120001-469
hexagonal nut
六角螺帽
470
120001-470
strap guide
导带板
473
120001-473
Cap screw
螺帽
474
120001-474
Spring washer
弹簧垫圈
475
120001-475
Cap screw
螺帽
476
120001-476
washer
垫圈
477
120001-477
Spring washer
弹簧垫圈
479
120001-479
Cap screw
螺帽
480
120001-480
tension seal

481
120001-481
feeder box retainer
分线箱
487
120001-487
eyebolt
吊环螺栓
488
120001-488
Cap screw
螺帽
490
120001-490
Cap screw
螺帽
491
120001-491
Cap screw
螺帽
492
120001-492
pneumatic cylinder
气压缸
493
120001-493
fork head
叉脚
494
120001-494
Swivel joint
回转接头
495
120001-495
locking washer
锁紧[止动, 防松]垫圈
497
120001-497
bellows
风箱
498
120001-498
feed wheel
滚轮
499
120001-499
feed wheel
滚轮
500
120001-500
cutter station
刀座
501
120001-501
pneumatic control
气动控制器
503
120001-503
junction box
接线盒
505
120001-505
lever mounting ,complete
档板
506
120001-506
hinged lever
铰链控制杆
507
120001-507
valve block,complete
给油阀组
508
120001-508
cylinder
汽缸
509
120001-509
blade housing with bushing
带轴衬的刀座
511
120001-511
retention pin
定位销
512
120001-512
kolben,kompl

517
120001-517
retention pin
定位销
518
120001-518
auxillary trotte
螺丝
520
120001-520
counter roller angle
连接板
521
120001-521
lever complete
夹板
522
120001-522
retention pin
定位销
527
120001-527
cylinder holding device
固定汽缸装置
528
120001-528
valve block
给油阀组
529
120001-529
motor flonge
偏心柱
607
120001-607
Cylindrical pin
筒形销
612
120001-612
Cylindrical pin
筒形销
900
120001-900
compressed air motor
气动马达
902
120001-902
compressed air motor for 19 strap width
气动马达19mm
1001
120001-1001
clamping piece
箝位挡板19mm
1002
120001-1002

箝位挡板25mm
1003
120001-1003

箝位挡板32mm
2201
120001-2201
clamping lever
夹紧手柄19mm
2202
120001-2202
clamping lever
夹紧手柄25mm
2203
120001-2203
clamping lever
夹紧手柄32mm
3001
120001-3001
bearing box
轴承座19mm
3002
120001-3002
bearing box
轴承座25mm
3003
120001-3003
bearing box
轴承座32mm
3401
120001-3401
feed wheel
滚轮19、25mm
3402
120001-3402
feed wheel
滚轮32mm
3461
120001-3461
guide
牵带轮19mm
3462
120001-3462
guide
牵带轮25mm
3463
120001-3463
guide
牵带轮32mm
3881
120001-3881
strap guide,left
左牵带轮19mm
3882
120001-3882
strap guide,left
左牵带轮25mm
3883
120001-3883
strap guide,left
左牵带轮32mm
3891
120001-3891
strap guide,right
右牵带轮19mm
3892
120001-3892
strap guide,right
右牵带轮25mm
3893
120001-3893
strap guide,right
右牵带轮32mm
3991
120001-3991
guide
牵带轮19mm
3992
120001-3992
guide
牵带轮25mm
3993
120001-3993
guide
牵带轮32mm
4050
120001-4050
bearing box
轴承座
4051
120001-4051
Cap screw
螺帽
4052
120001-4052
pressure spring
压力弹簧
4053
120001-4053
Cylindrical pin
筒形销
4054
120001-4054
plate
底片
4055
120001-4055
Cap screw
螺帽
4056
120001-4056
spring washer
弹簧垫圈
4057
120001-4057
initiator

4058
120001-4058
pawl
棘爪
4059
120001-4059
cylindrical pin
筒形销
4060
120001-4060
lever
受柄
4061
120001-4061
countersunk screw
锥型螺丝
4062
120001-4062
cylindrical pin
筒形销
4063
120001-4063
protective pin
保护销
4064
120001-4064
Cap screw
螺帽
4065
120001-4065
washer
垫圈
4066
120001-4066
contact plece

4067
120001-4067
Cap screw
螺帽
4068
120001-4068
washer
垫圈
4069
120001-4069
dowel pin
开槽销
4070
120001-4070
initiator
4057
4361
120001-4361
end support piece ,right
右端承底片19mm
4362
120001-4362
end support piece ,right
右端承底片25mm
4362
120001-4362
end support piece ,right
右端承底片32mm
4371
120001-4371
guide bar,right
右导向杆19mm
4372
120001-4372
guide bar,right
右导向杆25mm
4373
120001-4373
guide bar,right
右导向杆32mm
4391
120001-4391
guide bar,top
上导向杆19mm
4392
120001-4392
guide bar,top
上导向杆25mm
4393
120001-4393
guide bar,top
上导向杆32mm
4421
120001-4421
end support piece ,left
左端承底片19mm
4422
120001-4422
end support piece ,left
左端承底片25mm
4423
120001-4423
end support piece ,left
左端承底片32mm
4431
120001-4431
guide bar,left
左导向杆19mm
4432
120001-4432
guide bar,left
左导向杆25mm
4433
120001-4433
guide bar,left
左导向杆32mm
4781
120001-4781
flap step19+25
档板
4783
120001-4783
flap step32
档板
5041
120001-5041
drive for 19 mm strap

5042
120001-5042
drive for 20 mm strap

5043
120001-5043
drive for 21 mm strap

5101
120001-5101
cutter unit
切刀19mm
5102
120001-5102
cutter unit
切刀25mm
5103
120001-5103
cutter unit
切刀32mm
5231
120001-5231
guide block19
导块
5232
120001-5232
guide block25
导块
5233
120001-5233
guide block32
导块
5241
120001-5241
end support piece ,right
右端承底片19mm
5242
120001-5242
end support piece ,right
右端承底片25mm
5243
120001-5243
end support piece ,right
右端承底片32mm
5251
120001-5251
end support piece ,left
左端承底片19mm
5252
120001-5252
end support piece ,left
左端承底片25mm
5253
120001-5253
end support piece ,left
左端承底片32mm
5311
120001-5311
cutter unit
切刀19mm
5312
120001-5312
cutter unit
切刀25mm
5313
120001-5313
cutter unit
切刀32mm
5501
120001-5501
strapping headVS 31, , ,
打包机头19mm
5502
120001-5502
strapping headVS 32
打包机头25mm
5503
120001-5503
strapping headVS 33
打包机头32mm
5511
120001-5511
strapping headVS 31
打包机头19mm
5512
120001-5512
strapping headVS 32
打包机头25mm
5513
120001-5513
strapping headVS 33
打包机头32mm
6001
120001-6001
cutter plate,left
左切刀19mm
6001
120001-6001
cutter plate,left
左切刀25mm
6001
120001-6001
cutter plate,left
左切刀32mm
6011
120001-6011
centeral plate
底片
6012
120001-6012
centeral plate
底片
6013
120001-6013
centeral plate
底片
6021
120001-6021
lower plate,right,centeral
右下底片
6022
120001-6022
lower plate,right,centeral
右下底片
6023
120001-6023
lower plate,right,centeral
右下底片
6031
120001-6031
lower plate,left,centeral
左下底片
6032
120001-6032
lower plate,left,centeral
左下底片
6033
120001-6033
lower plate,left,centeral
左下底片
6041
120001-6041
articulated lever
铰接手柄
6042
120001-6042
articulated lever
铰接手柄
6043
120001-6043
articulated lever
铰接手柄
6081
120001-6081
upper cutter unit
上刀刃
6082
120001-6082
upper cutter unit
上刀刃
6083
120001-6083
upper cutter unit
上刀刃
6091
120001-6091
supporting bar
支撑杆
6092
120001-6092
supporting bar
支撑杆
6093
120001-6093
supporting bar
支撑杆
6101
120001-6101
Cap screw19+25mm
螺帽
6103
120001-6103
Cap screw32mm
螺帽
6111
120001-6111
distance plate
隔板
6112
120001-6112
distance plate
隔板
6113
120001-6113
distance plate
隔板

, <, DIV align=left>定位销
短号
长号
英文名
名称
2
120001-2
Cap screw
螺帽
3
120001-3
Spring washer
弹簧垫圈
4
120001-4
Heaf bar
夹板
5
120001-5
Cap screw
螺帽
6
120001-6
Federring
垫圈
8
120001-8
Cap screw
螺帽
9
120001-9
Spring washer
弹簧垫圈
10
120001-10
Cap screw
螺帽
11
120001-11
Plate
垫片
12
120001-12
Swivel joint
回转接头
13
120001-13
Pawl
棘爪
14
120001-14
Cylindrical pin
圆柱销
15
120001-15
Cylindrical pin
圆柱销
16
120001-16
Valve block
气阀塞子
17
120001-17
Cap screw
螺帽
18
120001-18
Ball
弹子
19
120001-19
Compression spring
弹簧
20
120001-20
round gasket
垫圈
21
120001-21
tappet
梃杆
22
120001-22
plug
插销
23
120001-23
hexagonal screw
螺丝
24
120001-24
Spring washer
弹簧垫圈
25
120001-25
initiator 20-250v
过顶板
26
120001-26
initiator 20-250v
过顶板
27
120001-27


28
120001-28
initiator 10-55v
过顶板
29
120001-29
initiator 10-55v
过顶板
30
120001-30
tube
气管
31
120001-31
initiator 10-55v
过顶板
32
120001-32
initiator 90-250v
过顶板
33
120001-33
Spring washer
弹簧垫圈
34
120001-34
hexagonal nut
六角螺帽
51
120001-51
Cylindrical pin
圆柱销
52
120001-52
round gasket
垫圈
53
120001-53
Swivel joint
回转接头
54
120001-54
cover plate
盖板
55
120001-55
Cap screw
螺帽
56
120001-56
Spring washer
弹簧垫圈
57
120001-57
cylinder
汽缸
58
120001-58
piston rod
定位杆
59
120001-59
Dowel pin
合缝销
60
120001-60
sheet metal
金属片
61
120001-61
Cap screw
螺帽
62
120001-62
Spring washer
弹簧垫圈
63
120001-63
washer
垫圈
64
120001-64
Cap screw
螺帽
65
120001-65
Spring washer
弹簧垫圈
66
120001-66
self-aligning ball bearing
自动对位轴承
67
120001-67
shim
薄垫片
68
120001-68
cylindercover
汽缸盖
69
120001-69
Cap screw
螺帽
70
120001-70
round gasket
垫圈
71
120001-71
Swivel joint
回转接头
72
120001-72
reducing nipple
变内径内螺纹接头
73
120001-73
piston
活塞
74
120001-74
piston packing
填密活塞
75
120001-75
piston guide ring
活塞环
76
120001-76
bushing
轴衬
77
120001-77
pistonrod packing
填密活塞
79
120001-79
Swivel joint
回转接头
80
120001-80
piston pin
活塞销
81
120001-81
piston
活塞
82
120001-82
washer
垫圈
83
120001-83
hexagonal nut
六角螺帽
84
120001-84
cylindercover
汽缸盖
85
120001-85
Cap screw
螺帽
86
120001-86
round gasket
垫圈
87
120001-87
Swivel joint
回转接头
88
120001-88
reducing nipple
变内径内螺纹接头
89
120001-89
receiving lug

91
120001-91
rod packing
O型圈
93
120001-93
spacer
垫片
94
120001-94
silver house
软管
95
,
120001-95
Swivel jo, , in, t
回转接头
96
120001-96
piston pin
活塞销
97
120001-97
sleeve
轴子
100
120001-100
terminal box

101
120001-101
Cap screw
螺帽
102
120001-102
Spring washer
弹簧垫圈
103
120001-103
Valve block
气阀塞子
104
120001-104
Cap screw
螺帽
105
120001-105
Cap screw
螺帽
106
120001-106
Spring washer
弹簧垫圈
107
120001-107
round gasket
垫圈
108
120001-108
round gasket
垫圈
109
120001-109
straight pipe union
直活管节
110
120001-110
Swivel joint
回转接头
111
120001-111
battery plate
蓄电池极板
112
120001-112
6/2 way valve
6/2式阀
113
120001-113
Cap screw
螺帽
114
120001-114
Swivel joint
回转接头
116
120001-116
silver house
软管
117
120001-117
silver house
软管
118
120001-118
pipe
气管
119
120001-119
pipe
气管
120
120001-120
silver house
软管
121
120001-121
pipe
气管
124
120001-124
straight pipe union
直活管节
125
120001-125
Swivel joint
回转接头
126
120001-126
silver house
软管
127
120001-127
silver house
软管
129
120001-129
pipe
气管
130
120001-130
Cap screw
螺帽
131
120001-131
Spring washer
弹簧垫圈
134
120001-134
round gasket
垫圈
135
120001-135
round gasket
垫圈
136
120001-136
2/2 way valve without

139
120001-139
joint
接头
140
120001-140
Swivel joint
回转接头
141
120001-141
silver house
软管
142
120001-142
Swivel joint
回转接头
143
120001-143
non reduced swivel joint
回转接头
144
120001-144
silver house
软管
145
120001-145
cone reducing connection
锥形接头
146
120001-146
adjustable l-connection
可调节的接头
147
120001-147
silver house
软管
148
120001-148
Swivel joint
回转接头
149
120001-149
transducer
转换器
150
120001-150
Cap screw
螺帽
151
120001-151
Cap screw
螺帽
152
120001-152
straight pipe union
直活管节
154
120001-154
5/4 way valve without
阀主心
155
120001-155
Cap screw
螺帽
156
120001-156
Swivel joint
回转接头
157
120001-157
straight pipe union
直活管节
158
120001-158
pipe
气管
159
120001-159
splash lubricator
润滑器
160
120001-160
reducing nipple
变内径内螺纹接头
161
120001-161
plug nipple
变内径内螺纹接头
162
120001-162
coupling
接头
164
120001-164
distance collar
定距环
170
120001-170
silencer
消声器
171
120001-171
pressure gauge
压力计
172
120001-172
interrnediate sheet
夹板
173
120001-173
5/4 way valve without
阀主心
174
120001-174
Cap screw
螺帽
175
120001-175
distance collar
定距环
176
120001-176
double check valve
双单向阀
177
120001-177
double nipple
双向短接管
180
120001-180
round gasket
垫圈
181
120001-181
throttle(reducing)screw
变径螺丝
182
120001-182
hexagonal nut
六角螺帽
183
120001-183
L-pipe union
L型接头
184
120001-184
cover
盖子
185
120001-185
countersink sewrew
锥形螺丝
186
120001-186
filter
过滤器
187
120001-187
sound absorber inset
内置减振器
188
120001-188
quick vent valve
快速排气阀
189
120001-189
straight pipe union
直活管节
190
120001-190
straight screwed socket
螺口插座
191
120001-191
gasket
垫圈
192
120001-192
actuating magnet
193
120001-193
conducing box with luminate
194
120001-194
actuating magnet
195
120001-195
conducing box with luminate
196
120001-196
actuating magnet
197
120001-197
conducing box with luminate
198
120001-198
actuating magnet
199
120001-199
conducing box with luminate
200
120001-200
clarnp holder
支架
201
120001-201
Cylinder pin
圆柱销
202
120001-202
Cylinder pin
圆柱销
203
120001-203
cutting plate ,right
右剪切板
205
120001-205
Cap screw
螺帽
207
120001-207
Cap screw
螺帽
208
120001-208
counter blade
对刃
209
120001-209
cutting blade
切刀
211
120001-211
spacer
垫片
212
120001-212
Cap screw
螺帽
213
120001-213
Spring washer
弹簧垫圈
216
120001-216
lower blade pin
下切刀销子
217
120001-217
withdrawal pin
轴杆
218
120001-218
roller
滚轴
219
120001-219
roller pin
滚针
221
120001-221
clamping sleeve
压紧套筒
222
120001-222
clamping sleeve
压紧套筒
223
120001-223
distance collar
定距环
224
120001-224
distance collar
定距环
225
120001-225
clarnping leaver pin
杆销
250
120001-250
hexagonal nut
六角螺帽
251
120001-251
tension washer
拉紧垫圈
252
120001-252
junction box
接线盒
253
120001-253
mounted housing

254
120001-254
plug insert
插栓
255
120001-255
screw connection
连接螺丝
256
120001-256
dummy plug
插销
257
120001-257
line-up terminal
一字型接线端
258
120001-258
end plate
侧板
259
120001-259
carrier rail
横杆
260
120001-260
fixed bridge

265
120001-265
arrow
标杆
266
120001-266
Cap screw
螺帽
267
120001-267
separating disc
圆盘
268
120001-268
end clamp
夹钳
269
120001-269
clamp for neutral
夹钳
270
120001-270
wire sleeve
金属丝袖子
271
120001-271
simplex card

272
120001-272
simplex card
271
273
120001-273
simplex card
271
301
120001-301
Cylinder pin
圆柱销
302
120001-302
Cylinder pin
圆柱销
303
120001-303
Cap screw
螺帽
304
120001-304
locking washer
锁紧垫圈
305
120001-305
guide roller
导向辊
306
120001-306
guide roller
导向辊
307
120001-307
drive housing
传动箱
308
120001-308
Cap screw
螺帽
309
120001-309
threaded pin
销子
310
120001-310
needle (roller)bearing
滚针轴承
311
120001-311
DU bushing
轴衬
312
120001-312
Cap screw
螺帽
313
120001-313
hexagonal nut
六角螺帽
314
120001-314
short stroke cylinder
短冲程汽缸
315
120001-315
Cap screw
螺帽
316
120001-316
Swivel joint
回转接头
317
120001-317
reducing nipple
变内径内螺纹接头
318
120001-318
pneumatic cylinder
气压缸
319
120001-319
Cap screw
螺帽
320
120001-320
Spring washer
弹簧垫圈
321
120001-321
straight pipe union
直活管节
325
120001-325
pin
销子
326
120001-326
hexagonal nut
六角螺帽
327
120001-327
tension washer
拉紧垫圈
328
120001-328
locking washer
锁紧垫圈
329
120001-329


330
120001-330
rocker
摇杆
331
120001-331
taper ball bearing
滚球轴承
332
120001-332
gasket
垫圈
333
120001-333
DU bushing
轴衬
334
120001-334
cover
盖子
335
120001-335
gasket
垫圈
336
120001-336
needle case
轴承
337
120001-337
Cap screw
螺帽
338
120001-338
transport shaft
传输轴
339
120001-339
retaining ring
定位环
341
120001-341
flange
凸缘
342
120001-342
Cap screw
螺帽
343
120001-343
Cap screw
螺帽
344
120001-344
spring pin
弹簧销子
345
120001-345
tension spring
张力簧
347
120001-347


348
120001-348
needle bushing
轴衬
349
120001-349
gasket
垫圈
350
120001-350


351
120001-351
needle bushing
轴衬
352
120001-352
gasket
垫圈
353
120001-353
counter roller
滚筒
354
120001-354
shaft
轴衬
355
120001-355
washer
垫圈
356
120001-356
retaining ring
定位环
357
120001-357
torsion spring
转矩弹簧
358
120001-358
washer
垫圈
359
120001-359
Cap screw
螺帽
360
120001-360
locking washer
锁紧垫圈
361
120001-361
shaft
轴衬
362
120001-362
adjusting spring
调整弹簧
377
120001-377
tight-fit spring
紧密配合弹簧
378
120001-378
Spring washer
弹簧垫圈
379
120001-379
hexagonal nut
六角螺帽
380
120001-380
Cap screw
螺帽
382
120001-382
inner ring
内环
383
120001-383
conter roller
滚筒
384
120001-384
eccentric
档板
385
120001-385
needle bushing
轴衬
386
120001-386
gasket
垫圈
387
120001-387
needle taper ball bearing
滚针轴承
390
120001-390
shaft
391
120001-391
adjusting spring
调整弹簧
392
120001-392
locking washer
锁紧垫圈
393
120001-393
retaining ring
定位环
394
120001-394
hinged lever,right
右铰链控制杆
395
120001-395
clamping sleeve
压紧套筒
400
120001-400
Cap screw
螺帽
401
120001-401
Spring washer
弹簧垫圈
403
120001-403
reducing nipple
变内径内螺纹接头
404
120001-404
bracket
支架
405
120001-405
Cap screw
螺帽
406
120001-406
locking washer
锁紧垫圈
407
120001-407
interrnadlate ring

408
120001-408
washer
垫圈
409
120001-409
contersunk screw
锥形螺丝
410
120001-410
slide rod
拉杆
411
120001-411
angle joint
角接头
412
120001-412
hexagonal nut
六角螺帽
413
120001-413
compressed air motor
气动马达
414
120001-414
straight pipe union
直活管节
416
120001-416
compressed air motor
气动马达
417
120001-417
spring pin
弹簧销子
418
120001-418
toothed wheel
齿轮
419
120001-419
dowel pin
开槽销
420
120001-420
rack
支架
421
120001-421
shaft
422
120001-422
flange
凸缘
423
120001-423
DU bushing
轴衬
424
120001-424
Cap screw
螺帽
425
120001-425
needle bushing
轴衬
426
120001-426
gasket
垫圈
427
120001-427
Cap screw
螺帽
428
120001-428
Spring washer
弹簧垫圈
429
120001-429
Cap screw
螺帽
430
120001-430
Cap screw
螺帽
431
120001-431
locking washer
锁紧垫圈
432
120001-432
Cap screw
螺帽
433
120001-433
Spring washer
弹簧垫圈
435
120001-435
E-angle screwing
螺纹角连接
438
120001-438
Cap screw
螺帽
440
120001-440
tightening disc
固定圆盘
441
120001-441
Cap screw
螺帽
444
120001-444
Cap screw
螺帽
446
120001-446
tightening disc
固定圆盘
447
120001-447
Cap screw
螺帽
450
120001-450
Cylindrical pin
圆柱销
451
120001-451
Cap screw
螺帽
452
120001-452
Spring washer
弹簧垫圈
453
120001-453
hexagonal nut
六角螺帽
455
120001-455
DU bushing
轴衬
460
120001-460
key
461
120001-461
Cap screw
螺帽
462
120001-462
locking washer
锁紧[止动, 防松]垫圈
465
120001-465
DU-washer
垫圈
468
120001-468
headless pin
无头销
469
120001-469
hexagonal nut
六角螺帽
470
120001-470
strap guide
导带板
473
120001-473
Cap screw
螺帽
474
120001-474
Spring washer
弹簧垫圈
475
120001-475
Cap screw
螺帽
476
120001-476
washer
垫圈
477
120001-477
Spring washer
弹簧垫圈
479
120001-479
Cap screw
螺帽
480
120001-480
tension seal

481
120001-481
feeder box retainer
分线箱
487
120001-487
eyebolt
吊环螺栓
488
120001-488
Cap screw
螺帽
490
120001-490
Cap screw
螺帽
491
120001-491
Cap screw
螺帽
492
120001-492
pneumatic cylinder
气压缸
493
120001-493
fork head
叉脚
494
120001-494
Swivel joint
回转接头
495
120001-495
locking washer
锁紧[止动, 防松]垫圈
497
120001-497
bellows
风箱
498
120001-498
feed wheel
滚轮
499
120001-499
feed wheel
滚轮
500
120001-500
cutter station
刀座
501
120001-501
pneumatic control
气动控制器
503
120001-503
junction box
接线盒
505
120001-505
lever mounting ,complete
档板
506
120001-506
hinged lever
铰链控制杆
507
120001-507
valve block,complete
给油阀组
508
120001-508
cylinder
汽缸
509
120001-509
blade housing with bushing
带轴衬的刀座
511
120001-5, 11
retention pin
512
120001-512
kolben,kompl

517
120001-517
retention pin
定位销
518
120001-518
auxillary trotte
螺丝
520
120001-520
counter roller angle
连接板
521
120001-521
lever complete
夹板
522
120001-522
retention pin
定位销
527
120001-527
cylinder holding device
固定汽缸装置
528
120001-528
valve block
给油阀组
529
120001-529
motor flonge
偏心柱
607
120001-607
Cylindrical pin
筒形销
612
120001-612
Cylindrical pin
筒形销
900
120001-900
compressed air motor
气动马达
902
120001-902
compressed air motor for 19 strap width
气动马达19mm
1001
120001-1001
clamping piece
箝位挡板19mm
1002
120001-1002

箝位挡板25mm
1003
120001-1003

箝位挡板32mm
2201
120001-2201
clamping lever
夹紧手柄19mm
2202
120001-2202
clamping lever
夹紧手柄25mm
2203
120001-2203
clamping lever
夹紧手柄32mm
3001
120001-3001
bearing box
轴承座19mm
3002
120001-3002
bearing box
轴承座25mm
3003
120001-3003
bearing box
轴承座32mm
3401
120001-3401
feed wheel
滚轮19、25mm
3402
120001-3402
feed wheel
滚轮32mm
3461
120001-3461
guide
牵带轮19mm
3462
120001-3462
guide
牵带轮25mm
3463
120001-3463
guide
牵带轮32mm
3881
120001-3881
strap guide,left
左牵带轮19mm
3882
120001-3882
strap guide,left
左牵带轮25mm
3883
120001-3883
strap guide,left
左牵带轮32mm
3891
120001-3891
strap guide,right
右牵带轮19mm
3892
120001-3892
strap guide,right
右牵带轮25mm
3893
120001-3893
strap guide,right
右牵带轮32mm
3991
120001-3991
guide
牵带轮19mm
3992
120001-3992
guide
牵带轮25mm
3993
120001-3993
guide
牵带轮32mm
4050
120001-4050
bearing box
轴承座
4051
120001-4051
Cap screw
螺帽
4052
120001-4052
pressure spring
压力弹簧
4053
120001-4053
Cylindrical pin
筒形销
4054
120001-4054
plate
底片
4055
120001-4055
Cap screw
螺帽
4056
120001-4056
spring washer
弹簧垫圈
4057
120001-4057
initiator

4058
120001-4058
pawl
棘爪
4059
120001-4059
cylindrical pin
筒形销
4060
120001-4060
lever
受柄
4061
120001-4061
countersunk screw
锥型螺丝
4062
120001-4062
cylindrical pin
筒形销
4063
120001-4063
protective pin
保护销
4064
120001-4064
Cap screw
螺帽
4065
120001-4065
washer
垫圈
4066
120001-4066
contact plece

4067
120001-4067
Cap screw
螺帽
4068
120001-4068
washer
垫圈
4069
120001-4069
dowel pin
开槽销
4070
120001-4070
initiator
4057
4361
120001-4361
end support piece ,right
右端承底片19mm
4362
120001-4362
end support piece ,right
右端承底片25mm
4362
120001-4362
end support piece ,right
右端承底片32mm
4371
120001-4371
guide bar,right
右导向杆19mm
4372
120001-4372, guide bar,right
右导向杆25mm

4373
120001-4373
guide bar,right
右导向杆32mm
4391
120001-4391
guide bar,top
上导向杆19mm
4392
120001-4392
guide bar,top
上导向杆25mm
4393
120001-4393
guide bar,top
上导向杆32mm
4421
120001-4421
end support piece ,left
左端承底片19mm
4422
120001-4422
end support piece ,left
左端承底片25mm
4423
120001-4423
end support piece ,left
左端承底片32mm
4431
120001-4431
guide bar,left
左导向杆19mm
4432
120001-4432
guide bar,left
左导向杆25mm
4433
120001-4433
guide bar,left
左导向杆32mm
4781
120001-4781
flap step19+25
档板
4783
120001-4783
flap step32
档板
5041
120001-5041
drive for 19 mm strap

5042
120001-5042
drive for 20 mm strap

5043
120001-5043
drive for 21 mm strap

5101
120001-5101
cutter unit
切刀19mm
5102
120001-5102
cutter unit
切刀25mm
5103
120001-5103
cutter unit
切刀32mm
5231
120001-5231
guide block19
导块
5232
120001-5232
guide block25
导块
5233
120001-5233
guide block32
导块
5241
120001-5241
end support piece ,right
右端承底片19mm
5242
120001-5242
end support piece ,right
右端承底片25mm
5243
120001-5243
end support piece ,right
右端承底片32mm
5251
120001-5251
end support piece ,left
左端承底片19mm
5252
120001-5252
end support piece ,left
左端承底片25mm
5253
120001-5253
end support piece ,left
左端承底片32mm
5311
120001-5311
cutter unit
切刀19mm
5312
120001-5312
cutter unit
切刀25mm
5313
120001-5313
cutter unit
切刀32mm
5501
120001-5501
strapping headVS 31
打包机头19mm
5502
120001-5502
strapping headVS 32
打包机头25mm
5503
120001-5503
strapping headVS 33
打包机头32mm
5511
120001-5511
strapping headVS 31
打包机头19mm
5512
120001-5512
strapping headVS 32
打包机头25mm
5513
120001-5513
strapping headVS 33
打包机头32mm
6001
120001-6001
cutter plate,left
左切刀19mm
6001
120001-6001
cutter plate,left
左切刀25mm
6001
120001-6001
cutter plate,left
左切刀32mm
6011
120001-6011
centeral plate
底片
6012
120001-6012
centeral plate
底片
6013
120001-6013
centeral plate
底片
6021
120001-6021
lower plate,right,centeral
右下底片
6022
120001-6022
lower plate,right,centeral
右下底片
6023
120001-6023
lower plate,right,centeral
右下底片
6031
120001-6031
lower plate,left,centeral
左下底片
6032
120001-6032
lower plate,left,centeral
左下底片
6033
120001-6033
lower plate,left,centeral
左下底片
6041
120001-6041
articulated lever
铰接手柄
6042
120001-6042
articulated lever
铰接手柄
6043
120001-6043
articulated lever
铰接手柄
6081
120001-6081
upper cutter unit
上刀刃
6082
120001-6082
upper cutter unit
上刀刃
6083
120001-6083
upper cutter unit
上刀刃
6091
120001-6091
supporting bar
支撑杆
6092
120001-6092
supporting bar
支撑杆
6093
120001-6093
supporting bar
支撑杆
6101
120001-6101
Cap screw19+25mm
螺帽
6103
120001-6103
Cap screw32mm
螺帽
6111
120001-6111
distance plate
隔板
6112
120001-6112
distance plate
隔板
6113
120001-6113
distance plate
隔板






, lt;, /TD>
120001-405
Cap screw
螺帽
406
120001-406
locking washer
锁紧垫圈
407
120001-407
interrnadlate ring

408
120001-408
washer
垫圈
409
120001-409
contersunk screw
锥形螺丝
410
120001-410
slide rod
拉杆
411
120001-411
angle joint
角接头
412
120001-412
hexagonal nut
六角螺帽
413
120001-413
compressed air motor
气动马达
414
120001-414
straight pipe union
直活管节
416
120001-416
compressed air motor
气动马达
417
120001-417
spring pin
弹簧销子
418
120001-418
toothed wheel
齿轮
419
120001-419
dowel pin
开槽销
420
120001-420
rack
支架
421
120001-421
shaft
422
120001-422
flange
凸缘
423
120001-423
DU bushing
轴衬
424
120001-424
Cap screw
螺帽
425
120001-425
needle bushing
轴衬
426
120001-426
gasket
垫圈
427
120001-427
Cap screw
螺帽
428
120001-428
Spring washer
弹簧垫圈
429
120001-429
Cap screw
螺帽
430
120001-430
Cap screw
螺帽
431
120001-431
locking washer
锁紧垫圈
432
120001-432
Cap screw
螺帽
433
120001-433
Spring washer
弹簧垫圈
435
120001-435
E-angle screwing
螺纹角连接
438
120001-438
Cap screw
螺帽
440
120001-440
tightening disc
固定圆盘
441
120001-441
Cap screw
螺帽
444
120001-444
Cap screw
螺帽
446
120001-446
tightening disc
固定圆盘
447
120001-447
Cap screw
螺帽
450
120001-450
Cylindrical pin
圆柱销
451
120001-451
Cap screw
螺帽
452
120001-452
Spring washer
弹簧垫圈
453
120001-453
hexagonal nut
六角螺帽
455
120001-455
DU bushing
轴衬
460
120001-460
key
461
120001-461
Cap screw
螺帽
462
120001-462
locking washer
锁紧[止动, 防松]垫圈
465
120001-465
DU-washer
垫圈
468
120001-468
headless pin
无头销
469
120001-469
hexagonal nut
六角螺帽
470
120001-470
strap guide
导带板
473
120001-473
Cap screw
螺帽
474
120001-474
Spring washer
弹簧垫圈
475
120001-475
Cap screw
螺帽
476
120001-476
washer
垫圈
477
120001-477
Spring washer
弹簧垫圈
479
120001-479
Cap screw
螺帽
480
120001-480
tension seal

481
120001-481
feeder box retainer
分线箱
487
120001-487
eyebolt
吊环螺栓
488
120001-488
Cap screw
螺帽
490
120001-490
Cap screw
螺帽
491
120001-491
Cap screw
螺帽
492
120001-492
pneumatic cylinder
气压缸
493
120001-493
fork head
叉脚
494
120001-494
Swivel joint
回转接头
495
120001-495
locking washer
锁紧[止动, 防松]垫圈
497
120001-497
bellows
风箱
498
120001-498
feed wheel
滚轮
499
120001-499
feed wheel
滚轮
500
120001-500
cutter station
刀座
501
120001-501
pneumatic control
气动控制器
503
120001-503
junction box
接线盒
505
120001-505
lever mounting ,complete
档板
506
120001-506
hinged lever
铰链控制杆
507
120001-507
valve block,complete
给油阀组
508
120001-508
cylinder
汽缸
509
120001-509
blade housing with bushing
带轴衬的刀座
511
120001-511
retention pin
定位销
512
120001-512
kolben,kompl

517
120001-517
retention pin
定位销
518
120001-518
auxillary trotte
螺丝
520
120001-520
counter roller angle
连接板
521
120001-521
lever complete
夹板
522
120001-522
retention pin
定位销
527
120001-527
cylinder holding device
固定汽缸装置
528
120001-528
valve block
给油阀组
529
120001-529
motor flonge
偏心柱
607
120001-607
Cylindrical pin
筒形销
612
120001-612
Cylindrical pin
筒形销
900
120001-900
compressed air motor
气动马达
902
120001-902
compressed air motor for 19 strap width
气动马达19mm
1001
120001-1001
clamping piece
箝位挡板19mm
1002
120001-1002

箝位挡板25mm
1003
120001-1003

箝位挡板32mm
2201
120001-2201
clamping lever
夹紧手柄19mm
2202
120001-2202
clamping lever
夹紧手柄25mm
2203
120001-2203
clamping lever
夹紧手柄32mm
3001
120001-3001
bearing box
轴承座19mm
3002
120001-3002
bearing box
轴承座25mm
3003
120001-3003
bearing box
轴承座32mm
3401
120001-3401
feed wheel
滚轮19、25mm
3402
120001-3402
feed wheel
滚轮32mm
3461
120001-3461
guide
牵带轮19mm
3462
120001-3462
guide
牵带轮25mm
3463
120001-3463
guide
牵带轮32mm
3881
120001-3881
strap guide,left
左牵带轮19mm
3882
120001-3882
strap guide,left
左牵带轮25mm
3883
120001-3883
strap guide,left
左牵带轮32mm
3891
120001-3891
strap guide,right
右牵带轮19mm
3892
120001-3892
strap guide,right
右牵带轮25mm
3893
120001-3893
strap guide,right
右牵带轮32mm
3991
120001-3991
guide
牵带轮19mm
3992
120001-3992
guide
牵带轮25mm
3993
120001-3993
guide
牵带轮32mm
4050
120001-4050
bearing box
轴承座
4051
120001-4051
Cap screw
螺帽
4052
120001-4052
pressure spring
压力弹簧
4053
120001-4053
Cylindrical pin
筒形销
4054
120001-4054
plate
底片
4055
120001-4055
Cap screw
螺帽
4056
120001-4056
spring washer
弹簧垫圈
4057
120001-4057
initiator

4058
120001-4058
pawl
棘爪
4059
120001-4059
cylindrical pin
筒形销
4060
120001-4060
lever
受柄
4061
120001-4061
countersunk screw
锥型螺丝
4062
120001-4062
cylindrical pin
筒形销
4063
120001-4063
protective pin
保护销
4064
120001-4064
Cap screw
螺帽
4065
120001-4065
washer
垫圈
4066
120001-4066
contact plece

4067
120001-4067
Cap screw
螺帽
4068
120001-4068
washer
垫圈
4069
120001-4069
dowel pin
开槽销
4070
120001-4070
initiator
4057
4361
120001-4361
end support piece ,right
右端承底片19mm
4362
120001-4362
end support piece ,right
右端承底片25mm
4362
120001-4362
end support piece ,right
右端承底片32mm
4371
120001-4371
guide bar,right
右导向杆19mm
4372
120001-4372
guide bar,right
右导向杆25mm
4373
120001-4373
guide bar,right
右导向杆32mm
4391
120001-4391
guide bar,top
上导向杆19mm
4392
120001-4392
guide bar,top
上导向杆25mm
4393
120001-4393
guide bar,top
上导向杆32mm
4421
120001-4421
end support piece ,left
左端承底片19mm
4422
120001-4422
end support piece ,left
左端承底片25mm
4423
120001-4423
end support piece ,left
左端承底片32mm
4431
120001-4431
guide bar,left
左导向杆19mm
4432
120001-4432
guide bar,left
左导向杆25mm
4433
120001-4433
guide bar,left
左导向杆32mm
4781
120001-4781
flap step19+25
档板
4783
120001-4783
flap step32
档板
5041
120001-5041
drive for 19 mm strap

5042
120001-5042
drive for 20 mm strap

5043
120001-5043
drive for 21 mm strap

5101
120001-5101
cutter unit
切刀19mm
5102
120001-5102
,
cutter unit
切刀25mm
5103
120001-5103
cutter unit
切刀32mm
5231
120001-5231
guide block19
导块
5232
120001-5232
guide block25
导块
5233
120001-5233
guide block32
导块
5241
120001-5241
end support piece ,right
右端承底片19mm
5242
120001-5242
end support piece ,right
右端承底片25mm
5243
120001-5243
end support piece ,right
右端承底片32mm
5251
120001-5251
end support piece ,left
左端承底片19mm
5252
120001-5252
end support piece ,left
左端承底片25mm
5253
120001-5253
end support piece ,left
左端承底片32mm
5311
120001-5311
cutter unit
切刀19mm
5312
120001-5312
cutter unit
切刀25mm
5313
120001-5313
cutter unit
切刀32mm
5501
120001-5501
strapping headVS 31, , ,
打包机头19mm
5502
120001-5502
strapping headVS 32
打包机头25mm
5503
120001-5503
strapping headVS 33
打包机头32mm
5511
120001-5511
strapping headVS 31
打包机头19mm
5512
120001-5512
strapping headVS 32
打包机头25mm
5513
120001-5513
strapping headVS 33
打包机头32mm
6001
120001-6001
cutter plate,left
左切刀19mm
6001
120001-6001
cutter plate,left
左切刀25mm
6001
120001-6001
cutter plate,left
左切刀32mm
6011
120001-6011
centeral plate
底片
6012
120001-6012
centeral plate
底片
6013
120001-6013
centeral plate
底片
6021
120001-6021
lower plate,right,centeral
右下底片
6022
120001-6022
lower plate,right,centeral
右下底片
6023
120001-6023
lower plate,right,centeral
右下底片
6031
120001-6031
lower plate,left,centeral
左下底片
6032
120001-6032
lower plate,left,centeral
左下底片
6033
120001-6033
lower plate,left,centeral
左下底片
6041
120001-6041
articulated lever
铰接手柄
6042
120001-6042
articulated lever
铰接手柄
6043
120001-6043
articulated lever
铰接手柄
6081
120001-6081
upper cutter unit
上刀刃
6082
120001-6082
upper cutter unit
上刀刃
6083
120001-6083
upper cutter unit
上刀刃
6091
120001-6091
supporting bar
支撑杆
6092
120001-6092
supporting bar
支撑杆
6093
120001-6093
supporting bar
支撑杆
6101
120001-6101
Cap screw19+25mm
螺帽
6103
120001-6103
Cap screw32mm
螺帽
6111
120001-6111
distance plate
隔板
6112
120001-6112
distance plate
隔板
6113
120001-6113
distance plate
隔板

<, DIV align=left>定位销
短号
长号
英文名
名称
2
120001-2
Cap screw
螺帽
3
120001-3
Spring washer
弹簧垫圈
4
120001-4
Heaf bar
夹板
5
120001-5
Cap screw
螺帽
6
120001-6
Federring
垫圈
8
120001-8
Cap screw
螺帽
9
120001-9
Spring washer
弹簧垫圈
10
120001-10
Cap screw
螺帽
11
120001-11
Plate
垫片
12
120001-12
Swivel joint
回转接头
13
120001-13
Pawl
棘爪
14
120001-14
Cylindrical pin
圆柱销
15
120001-15
Cylindrical pin
圆柱销
16
120001-16
Valve block
气阀塞子
17
120001-17
Cap screw
螺帽
18
120001-18
Ball
弹子
19
120001-19
Compression spring
弹簧
20
120001-20
round gasket
垫圈
21
120001-21
tappet
梃杆
22
120001-22
plug
插销
23
120001-23
hexagonal screw
螺丝
24
120001-24
Spring washer
弹簧垫圈
25
120001-25
initiator 20-250v
过顶板
26
120001-26
initiator 20-250v
过顶板
27
120001-27


28
120001-28
initiator 10-55v
过顶板
29
120001-29
initiator 10-55v
过顶板
30
120001-30
tube
气管
31
120001-31
initiator 10-55v
过顶板
32
120001-32
initiator 90-250v
过顶板
33
120001-33
Spring washer
弹簧垫圈
34
120001-34
hexagonal nut
六角螺帽
51
120001-51
Cylindrical pin
圆柱销
52
120001-52
round gasket
垫圈
53
120001-53
Swivel joint
回转接头
54
120001-54
cover plate
盖板
55
120001-55
Cap screw
螺帽
56
120001-56
Spring washer
弹簧垫圈
57
120001-57
cylinder
汽缸
58
120001-58
piston rod
定位杆
59
120001-59
Dowel pin
合缝销
60
120001-60
sheet metal
金属片
61
120001-61
Cap screw
螺帽
62
120001-62
Spring washer
弹簧垫圈
63
120001-63
washer
垫圈
64
120001-64
Cap screw
螺帽
65
120001-65
Spring washer
弹簧垫圈
66
120001-66
self-aligning ball bearing
自动对位轴承
67
120001-67
shim
薄垫片
68
120001-68
cylindercover
汽缸盖
69
120001-69
Cap screw
螺帽
70
120001-70
round gasket
垫圈
71
120001-71
Swivel joint
回转接头
72
120001-72
reducing nipple
变内径内螺纹接头
73
120001-73
piston
活塞
74
120001-74
piston packing
填密活塞
75
120001-75
piston guide ring
活塞环
76
120001-76
bushing
轴衬
77
120001-77
pistonrod packing
填密活塞
79
120001-79
Swivel joint
回转接头
80
120001-80
piston pin
活塞销
81
120001-81
piston
活塞
82
120001-82
washer
垫圈
83
120001-83
hexagonal nut
六角螺帽
84
120001-84
cylindercover
汽缸盖
85
120001-85
Cap screw
螺帽
86
120001-86
round gasket
垫圈
87
120001-87
Swivel joint
回转接头
88
120001-88
reducing nipple
变内径内螺纹接头
89
120001-89
receiving lug

91
120001-91
rod packing
O型圈
93
120001-93
spacer
垫片
94
120001-94
silver house
软管
95
,
120001-95
Swivel jo, , in, t
回转接头
96
120001-96
piston pin
活塞销
97
120001-97
sleeve
轴子
100
120001-100
terminal box

101
120001-101
Cap screw
螺帽
102
120001-102
Spring washer
弹簧垫圈
103
120001-103
Valve block
气阀塞子
104
120001-104
Cap screw
螺帽
105
120001-105
Cap screw
螺帽
106
120001-106
Spring washer
弹簧垫圈
107
120001-107
round gasket
垫圈
108
120001-108
round gasket
垫圈
109
120001-109
straight pipe union
直活管节
110
120001-110
Swivel joint
回转接头
111
120001-111
battery plate
蓄电池极板
112
120001-112
6/2 way valve
6/2式阀
113
120001-113
Cap screw
螺帽
114
120001-114
Swivel joint
回转接头
116
120001-116
silver house
软管
117
120001-117
silver house
软管
118
120001-118
pipe
气管
119
120001-119
pipe
气管
120
120001-120
silver house
软管
121
120001-121
pipe
气管
124
120001-124
straight pipe union
直活管节
125
120001-125
Swivel joint
回转接头
126
120001-126
silver house
软管
127
120001-127
silver house
软管
129
120001-129
pipe
气管
130
120001-130
Cap screw
螺帽
131
120001-131
Spring washer
弹簧垫圈
134
120001-134
round gasket
垫圈
135
120001-135
round gasket
垫圈
136
120001-136
2/2 way valve without

139
120001-139
joint
接头
140
120001-140
Swivel joint
回转接头
141
120001-141
silver house
软管
142
120001-142
Swivel joint
回转接头
143
120001-143
non reduced swivel joint
回转接头
144
120001-144
silver house
软管
145
120001-145
cone reducing connection
锥形接头
146
120001-146
adjustable l-connection
可调节的接头
147
120001-147
silver house
软管
148
120001-148
Swivel joint
回转接头
149
120001-149
transducer
转换器
150
120001-150
Cap screw
螺帽
151
120001-151
Cap screw
螺帽
152
120001-152
straight pipe union
直活管节
154
120001-154
5/4 way valve without
阀主心
155
120001-155
Cap screw
螺帽
156
120001-156
Swivel joint
回转接头
157
120001-157
straight pipe union
直活管节
158
120001-158
pipe
气管
159
120001-159
splash lubricator
润滑器
160
120001-160
reducing nipple
变内径内螺纹接头
161
120001-161
plug nipple
变内径内螺纹接头
162
120001-162
coupling
接头
164
120001-164
distance collar
定距环
170
120001-170
silencer
消声器
171
120001-171
pressure gauge
压力计
172
120001-172
interrnediate sheet
夹板
173
120001-173
5/4 way valve without
阀主心
174
120001-174
Cap screw
螺帽
175
120001-175
distance collar
定距环
176
120001-176
double check valve
双单向阀
177
120001-177
double nipple
双向短接管
180
120001-180
round gasket
垫圈
181
120001-181
throttle(reducing)screw
变径螺丝
182
120001-182
hexagonal nut
六角螺帽
183
120001-183
L-pipe union
L型接头
184
120001-184
cover
盖子
185
120001-185
countersink sewrew
锥形螺丝
186
120001-186
filter
过滤器
187
120001-187
sound absorber inset
内置减振器
188
120001-188
quick vent valve
快速排气阀
189
120001-189
straight pipe union
直活管节
190
120001-190
straight screwed socket
螺口插座
191
120001-191
gasket
垫圈
192
120001-192
actuating magnet
193
120001-193
conducing box with luminate
194
120001-194
actuating magnet
195
120001-195
conducing box with luminate
196
120001-196
actuating magnet
197
120001-197
conducing box with luminate
198
120001-198
actuating magnet
199
120001-199
conducing box with luminate
200
120001-200
clarnp holder
支架
201
120001-201
Cylinder pin
圆柱销
202
120001-202
Cylinder pin
圆柱销
203
120001-203
cutting plate ,right
右剪切板
205
120001-205
Cap screw
螺帽
207
120001-207
Cap screw
螺帽
208
120001-208
counter blade
对刃
209
120001-209
cutting blade
切刀
211
120001-211
spacer
垫片
212
120001-212
Cap screw
螺帽
213
120001-213
Spring washer
弹簧垫圈
216
120001-216
lower blade pin
下切刀销子
217
120001-217
withdrawal pin
轴杆
218
120001-218
roller
滚轴
219
120001-219
roller pin
滚针
221
120001-221
clamping sleeve
压紧套筒
222
120001-222
clamping sleeve
压紧套筒
223
120001-223
distance collar
定距环
224
120001-224
distance collar
定距环
225
120001-225
clarnping leaver pin
杆销
250
120001-250
hexagonal nut
六角螺帽
251
120001-251
tension washer
拉紧垫圈
252
120001-252
junction box
接线盒
253
120001-253
mounted housing

254
120001-254
plug insert
插栓
255
120001-255
screw connection
连接螺丝
256
120001-256
dummy plug
插销
257
120001-257
line-up terminal
一字型接线端
258
120001-258
end plate
侧板
259
120001-259
carrier rail
横杆
260
120001-260
fixed bridge

265
120001-265
arrow
标杆
266
120001-266
Cap screw
螺帽
267
120001-267
separating disc
圆盘
268
120001-268
end clamp
夹钳
269
120001-269
clamp for neutral
夹钳
270
120001-270
wire sleeve
金属丝袖子
271
120001-271
simplex card

272
120001-272
simplex card
271
273
120001-273
simplex card
271
301
120001-301
Cylinder pin
圆柱销
302
120001-302
Cylinder pin
圆柱销
303
120001-303
Cap screw
螺帽
304
120001-304
locking washer
锁紧垫圈
305
120001-305
guide roller
导向辊
306
120001-306
guide roller
导向辊
307
120001-307
drive housing
传动箱
308
120001-308
Cap screw
螺帽
309
120001-309
threaded pin
销子
310
120001-310
needle (roller)bearing
滚针轴承
311
120001-311
DU bushing
轴衬
312
120001-312
Cap screw
螺帽
313
120001-313
hexagonal nut
六角螺帽
314
120001-314
short stroke cylinder
短冲程汽缸
315
120001-315
Cap screw
螺帽
316
120001-316
Swivel joint
回转接头
317
120001-317
reducing nipple
变内径内螺纹接头
318
120001-318
pneumatic cylinder
气压缸
319
120001-319
Cap screw
螺帽
320
120001-320
Spring washer
弹簧垫圈
321
120001-321
straight pipe union
直活管节
325
120001-325
pin
销子
326
120001-326
hexagonal nut
六角螺帽
327
120001-327
tension washer
拉紧垫圈
328
120001-328
locking washer
锁紧垫圈
329
120001-329


330
120001-330
rocker
摇杆
331
120001-331
taper ball bearing
滚球轴承
332
120001-332
gasket
垫圈
333
120001-333
DU bushing
轴衬
334
120001-334
cover
盖子
335
120001-335
gasket
垫圈
336
120001-336
needle case
轴承
337
120001-337
Cap screw
螺帽
338
120001-338
transport shaft
传输轴
339
120001-339
retaining ring
定位环
341
120001-341
flange
凸缘
342
120001-342
Cap screw
螺帽
343
120001-343
Cap screw
螺帽
344
120001-344
spring pin
弹簧销子
345
120001-345
tension spring
张力簧
347
120001-347


348
120001-348
needle bushing
轴衬
349
120001-349
gasket
垫圈
350
120001-350


351
120001-351
needle bushing
轴衬
352
120001-352
gasket
垫圈
353
120001-353
counter roller
滚筒
354
120001-354
shaft
轴衬
355
120001-355
washer
垫圈
356
120001-356
retaining ring
定位环
357
120001-357
torsion spring
转矩弹簧
358
120001-358
washer
垫圈
359
120001-359
Cap screw
螺帽
360
120001-360
locking washer
锁紧垫圈
361
120001-361
shaft
轴衬
362
120001-362
adjusting spring
调整弹簧
377
120001-377
tight-fit spring
紧密配合弹簧
378
120001-378
Spring washer
弹簧垫圈
379
120001-379
hexagonal nut
六角螺帽
380
120001-380
Cap screw
螺帽
382
120001-382
inner ring
内环
383
120001-383
conter roller
滚筒
384
120001-384
eccentric
档板
385
120001-385
needle bushing
轴衬
386
120001-386
gasket
垫圈
387
120001-387
needle taper ball bearing
滚针轴承
390
120001-390
shaft
391
120001-391
adjusting spring
调整弹簧
392
120001-392
locking washer
锁紧垫圈
393
120001-393
retaining ring
定位环
394
120001-394
hinged lever,right
右铰链控制杆
395
120001-395
clamping sleeve
压紧套筒
400
120001-400
Cap screw
螺帽
401
120001-401
Spring washer
弹簧垫圈
403
120001-403
reducing nipple
变内径内螺纹接头
404
120001-404
bracket
支架
405
120001-405
Cap screw
螺帽
406
120001-406
locking washer
锁紧垫圈
407
120001-407
interrnadlate ring

408
120001-408
washer
垫圈
409
120001-409
contersunk screw
锥形螺丝
410
120001-410
slide rod
拉杆
411
120001-411
angle joint
角接头
412
120001-412
hexagonal nut
六角螺帽
413
120001-413
compressed air motor
气动马达
414
120001-414
straight pipe union
直活管节
416
120001-416
compressed air motor
气动马达
417
120001-417
spring pin
弹簧销子
418
120001-418
toothed wheel
齿轮
419
120001-419
dowel pin
开槽销
420
120001-420
rack
支架
421
120001-421
shaft
422
120001-422
flange
凸缘
423
120001-423
DU bushing
轴衬
424
120001-424
Cap screw
螺帽
425
120001-425
needle bushing
轴衬
426
120001-426
gasket
垫圈
427
120001-427
Cap screw
螺帽
428
120001-428
Spring washer
弹簧垫圈
429
120001-429
Cap screw
螺帽
430
120001-430
Cap screw
螺帽
431
120001-431
locking washer
锁紧垫圈
432
120001-432
Cap screw
螺帽
433
120001-433
Spring washer
弹簧垫圈
435
120001-435
E-angle screwing
螺纹角连接
438
120001-438
Cap screw
螺帽
440
120001-440
tightening disc
固定圆盘
441
120001-441
Cap screw
螺帽
444
120001-444
Cap screw
螺帽
446
120001-446
tightening disc
固定圆盘
447
120001-447
Cap screw
螺帽
450
120001-450
Cylindrical pin
圆柱销
451
120001-451
Cap screw
螺帽
452
120001-452
Spring washer
弹簧垫圈
453
120001-453
hexagonal nut
六角螺帽
455
120001-455
DU bushing
轴衬
460
120001-460
key
461
120001-461
Cap screw
螺帽
462
120001-462
locking washer
锁紧[止动, 防松]垫圈
465
120001-465
DU-washer
垫圈
468
120001-468
headless pin
无头销
469
120001-469
hexagonal nut
六角螺帽
470
120001-470
strap guide
导带板
473
120001-473
Cap screw
螺帽
474
120001-474
Spring washer
弹簧垫圈
475
120001-475
Cap screw
螺帽
476
120001-476
washer
垫圈
477
120001-477
Spring washer
弹簧垫圈
479
120001-479
Cap screw
螺帽
480
120001-480
tension seal

481
120001-481
feeder box retainer
分线箱
487
120001-487
eyebolt
吊环螺栓
488
120001-488
Cap screw
螺帽
490
120001-490
Cap screw
螺帽
491
120001-491
Cap screw
螺帽
492
120001-492
pneumatic cylinder
气压缸
493
120001-493
fork head
叉脚
494
120001-494
Swivel joint
回转接头
495
120001-495
locking washer
锁紧[止动, 防松]垫圈
497
120001-497
bellows
风箱
498
120001-498
feed wheel
滚轮
499
120001-499
feed wheel
滚轮
500
120001-500
cutter station
刀座
501
120001-501
pneumatic control
气动控制器
503
120001-503
junction box
接线盒
505
120001-505
lever mounting ,complete
档板
506
120001-506
hinged lever
铰链控制杆
507
120001-507
valve block,complete
给油阀组
508
120001-508
cylinder
汽缸
509
120001-509
blade housing with bushing
带轴衬的刀座
511
120001-5, 11
retention pin
512
120001-512
kolben,kompl

517
120001-517
retention pin
定位销
518
120001-518
auxillary trotte
螺丝
520
120001-520
counter roller angle
连接板
521
120001-521
lever complete
夹板
522
120001-522
retention pin
定位销
527
120001-527
cylinder holding device
固定汽缸装置
528
120001-528
valve block
给油阀组
529
120001-529
motor flonge
偏心柱
607
120001-607
Cylindrical pin
筒形销
612
120001-612
Cylindrical pin
筒形销
900
120001-900
compressed air motor
气动马达
902
120001-902
compressed air motor for 19 strap width
气动马达19mm
1001
120001-1001
clamping piece
箝位挡板19mm
1002
120001-1002

箝位挡板25mm
1003
120001-1003

箝位挡板32mm
2201
120001-2201
clamping lever
夹紧手柄19mm
2202
120001-2202
clamping lever
夹紧手柄25mm
2203
120001-2203
clamping lever
夹紧手柄32mm
3001
120001-3001
bearing box
轴承座19mm
3002
120001-3002
bearing box
轴承座25mm
3003
120001-3003
bearing box
轴承座32mm
3401
120001-3401
feed wheel
滚轮19、25mm
3402
120001-3402
feed wheel
滚轮32mm
3461
120001-3461
guide
牵带轮19mm
3462
120001-3462
guide
牵带轮25mm
3463
120001-3463
guide
牵带轮32mm
3881
120001-3881
strap guide,left
左牵带轮19mm
3882
120001-3882
strap guide,left
左牵带轮25mm
3883
120001-3883
strap guide,left
左牵带轮32mm
3891
120001-3891
strap guide,right
右牵带轮19mm
3892
120001-3892
strap guide,right
右牵带轮25mm
3893
120001-3893
strap guide,right
右牵带轮32mm
3991
120001-3991
guide
牵带轮19mm
3992
120001-3992
guide
牵带轮25mm
3993
120001-3993
guide
牵带轮32mm
4050
120001-4050
bearing box
轴承座
4051
120001-4051
Cap screw
螺帽
4052
120001-4052
pressure spring
压力弹簧
4053
120001-4053
Cylindrical pin
筒形销
4054
120001-4054
plate
底片
4055
120001-4055
Cap screw
螺帽
4056
120001-4056
spring washer
弹簧垫圈
4057
120001-4057
initiator

4058
120001-4058
pawl
棘爪
4059
120001-4059
cylindrical pin
筒形销
4060
120001-4060
lever
受柄
4061
120001-4061
countersunk screw
锥型螺丝
4062
120001-4062
cylindrical pin
筒形销
4063
120001-4063
protective pin
保护销
4064
120001-4064
Cap screw
螺帽
4065
120001-4065
washer
垫圈
4066
120001-4066
contact plece

4067
120001-4067
Cap screw
螺帽
4068
120001-4068
washer
垫圈
4069
120001-4069
dowel pin
开槽销
4070
120001-4070
initiator
4057
4361
120001-4361
end support piece ,right
右端承底片19mm
4362
120001-4362
end support piece ,right
右端承底片25mm
4362
120001-4362
end support piece ,right
右端承底片32mm
4371
120001-4371
guide bar,right
右导向杆19mm
4372
120001-4372, guide bar,right
右导向杆25mm

4373
120001-4373
guide bar,right
右导向杆32mm
4391
120001-4391
guide bar,top
上导向杆19mm
4392
120001-4392
guide bar,top
上导向杆25mm
4393
120001-4393
guide bar,top
上导向杆32mm
4421
120001-4421
end support piece ,left
左端承底片19mm
4422
120001-4422
end support piece ,left
左端承底片25mm
4423
120001-4423
end support piece ,left
左端承底片32mm
4431
120001-4431
guide bar,left
左导向杆19mm
4432
120001-4432
guide bar,left
左导向杆25mm
4433
120001-4433
guide bar,left
左导向杆32mm
4781
120001-4781
flap step19+25
档板
4783
120001-4783
flap step32
档板
5041
120001-5041
drive for 19 mm strap

5042
120001-5042
drive for 20 mm strap

5043
120001-5043
drive for 21 mm strap

5101
120001-5101
cutter unit
切刀19mm
5102
120001-5102
cutter unit
切刀25mm
5103
120001-5103
cutter unit
切刀32mm
5231
120001-5231
guide block19
导块
5232
120001-5232
guide block25
导块
5233
120001-5233
guide block32
导块
5241
120001-5241
end support piece ,right
右端承底片19mm
5242
120001-5242
end support piece ,right
右端承底片25mm
5243
120001-5243
end support piece ,right
右端承底片32mm
5251
120001-5251
end support piece ,left
左端承底片19mm
5252
120001-5252
end support piece ,left
左端承底片25mm
5253
120001-5253
end support piece ,left
左端承底片32mm
5311
120001-5311
cutter unit
切刀19mm
5312
120001-5312
cutter unit
切刀25mm
5313
120001-5313
cutter unit
切刀32mm
5501
120001-5501
strapping headVS 31
打包机头19mm
5502
120001-5502
strapping headVS 32
打包机头25mm
5503
120001-5503
strapping headVS 33
打包机头32mm
5511
120001-5511
strapping headVS 31
打包机头19mm
5512
120001-5512
strapping headVS 32
打包机头25mm
5513
120001-5513
strapping headVS 33
打包机头32mm
6001
120001-6001
cutter plate,left
左切刀19mm
6001
120001-6001
cutter plate,left
左切刀25mm
6001
120001-6001
cutter plate,left
左切刀32mm
6011
120001-6011
centeral plate
底片
6012
120001-6012
centeral plate
底片
6013
120001-6013
centeral plate
底片
6021
120001-6021
lower plate,right,centeral
右下底片
6022
120001-6022
lower plate,right,centeral
右下底片
6023
120001-6023
lower plate,right,centeral
右下底片
6031
120001-6031
lower plate,left,centeral
左下底片
6032
120001-6032
lower plate,left,centeral
左下底片
6033
120001-6033
lower plate,left,centeral
左下底片
6041
120001-6041
articulated lever
铰接手柄
6042
120001-6042
articulated lever
铰接手柄
6043
120001-6043
articulated lever
铰接手柄
6081
120001-6081
upper cutter unit
上刀刃
6082
120001-6082
upper cutter unit
上刀刃
6083
120001-6083
upper cutter unit
上刀刃
6091
120001-6091
supporting bar
支撑杆
6092
120001-6092
supporting bar
支撑杆
6093
120001-6093
supporting bar
支撑杆
6101
120001-6101
Cap screw19+25mm
螺帽
6103
120001-6103
Cap screw32mm
螺帽
6111
120001-6111
distance plate
隔板
6112
120001-6112
distance plate
隔板
6113
120001-6113
distance plate
隔板






关注上海微信
